ABB ACS800-U1 User Manual

164 Resistor braking
400 V units
-0003-3 1.1 SACE08RE44 44 210 1
-0004-3 1.5 SACE08RE44 44 210 1
-0005-3 2.2 SACE08RE44 44 210 1
-0006-3 3.0 SACE08RE44 44 210 1
-0009-3 4.0 SACE08RE44 44 210 1
-0011-3 5.5 SACE15RE22 22 420 2
-0016-3 7.5 SACE15RE22 22 420 2
-0020-3 11 SACE15RE22 22 420 2
-0025-3 23 SACE15RE13 13 435 2
-0030-3 28 SACE15RE13 13 435 2
-0040-3 33 SAFUR90F575 8 1800 4.5
-0050-3 45 SAFUR90F575 8 1800 4.5
-0060-3 56 SAFUR90F575 8 1800 4.5
-0075-3 70 SAFUR80F500 6 2400 6
-0070-3 * 68 SAFUR80F500 6 2400 6
-0100-3 83 SAFUR125F500 4 3600 9
-0120-3 113 SAFUR125F500 4 3600 9
-0135-3 132 SAFUR200F500 2.7 5400 13.5
-0165-3 132 SAFUR200F500 2.7 5400 13.5
-0205-3 160 SAFUR200F500 2.7 5400 13.5
500 V units
-0004-5 1.5 SACE08RE44 44 210 1
-0005-5 2.2 SACE08RE44 44 210 1
-0006-5 3.0 SACE08RE44 44 210 1
-0009-5 4.0 SACE08RE44 44 210 1
-0011-5 5.5 SACE08RE44 44 210 1
-0016-5 7.5 SACE15RE22 22 420 2
-0020-5 11 SACE15RE22 22 420 2
-0025-5 15 SACE15RE22 22 420 2
-0030-5 28 SACE15RE13 13 435 2
-0040-5 33 SACE15RE13 13 435 2
-0050-5 45 SAFUR90F575 8 1800 4.5
-0060-5 56 SAFUR90F575 8 1800 4.5
-0070-5 68 SAFUR90F575 8 1800 4.5
-0105-5 83 SAFUR80F500 6 2400 6
-0100-5 * 83 SAFUR125F500 4 3600 9
-0120-5 113 SAFUR125F500 4 3600 9
-0140-5 135 SAFUR125F500 4 3600 9
-0165-5 160 SAFUR125F500 4 3600 9
-0205-5 160 SAFUR125F500 4 3600 9
-0255-5 200 SAFUR200F500 2.7 5400 13.5
ACS800-01 type
ACS800-U1 type
Braking power
of the chopper
and the drive
Brake resistor(s)
P
brcont
(kW)
Type R
(ohm)
E
R
(kJ)
P
Rcont
(kW)
