ABB CoriolisMaster FCB330 User Manual

48 CI/FCB300/FCH300-EN Rev. F | CoriolisMaster FCB330, FCB350, FCH330, FCH350
9.2.1 Process display
The process display appears on the LCD display when the
device is switched on. It shows information about the device
and current process values.
→ V 98.14 %
1
→
V 12,000 m
3
2
Fig. 31: Process display
1 1st line of the process display |
2 2nd line of the process display
The way in which the current process values are shown in
lines 1 and 2 can be adjusted on the configuration level.
Symbol Description
→
Display in forward direction
← Display in reverse direction
Error messages on the LCD display
In the event of an error, a message appears on the process
display. The text displayed provides information about the area
in which the error has occurred.
Process display
Error message
IMPORTANT (NOTE)
For a detailed error description and information
on troubleshooting, refer to the operating
instructions for the device.
9.2.2 Switching to the configuration level
(parameterization)
The device parameters can be displayed and changed on the
configuration level.
IMPORTANT (NOTE)
If the message "Error – operating protection"
appears on the LCD display, hardware write
protection has been activated with the operating
protection switch.
→ V 98.14 %
→ V 12.000 m3
1. Use to switch to the configuration level: A menu
option now appears at random on the LCD display.
2. Use or to select the "Prog. level" submenu
and (ENTER function) to select edit mode.
*Prog. level
Blocked
3. Use or to select the "Specialist" access level.
4. Use (ENTER function) to confirm your
settings.
If a password has been set (Prog. Prot. Code) you must enter
it now.
Prog. Prot. Code
****
5. Use to set the required value (the decimal position is
incremented every time the button is pressed).
6. Use to select the next decimal position.
7. Use (ENTER function) to confirm your
settings.
After the correct password has been entered, the
corresponding access level is opened. If the "Service"
programming level was selected, then the service password
must be entered.
The LCD display now indicates the first menu item on the
configuration level.
8. Use or to select a menu.
9. Use (ENTER function) to confirm your
selection.
