3.2.3.3 Parameter window AB: Output (valve drive, motor-driven (3-point))
All settings for output A/B as valve drive, motor-driven (3-point) are made in this parameter window.
Note
This parameter window is visible for the products FCA/S 1.1.1.2 and FCA/S 1.1.2.2.
These parameters appear if the option Valve drive, motor-driven (3-point) has been selected for the
outputs.
Reversing time
Options:
100, 300, 500, 700, 1,000 ms
This parameter defines the reversing delay time of the valve drive.
Note
The technical data of the valve drive must be observed!
