ABB i-bus KNX User Manual

ABB i-bus
®
KNX
Commissioning
236 2CDC508134D0202 | FCA/S 1.x.x.1
3.3.5.4 Communication objects Heating/Cooling
120
Toggle heating
General
1 bit
DPT 1.100
C, W
If a fan coil operating mode with switching object is selected in the Parameter window Enable output A...D, p. 76, the
parameter Toggle to heating with will appear. Depending on the selection, the communication object Toggle heating decides
whether to use heating or cooling mode.
Telegram value:
0 = Heating
1 = Cooling
121
Valve control values parallel mode
General
1 bit
DPT 1.100
C, W
If a fan coil operating mode with two control values and two valves is selected in Parameter window Enable output A...D,
p. 76, the parameter communication object "Valve control values parallel mode" 1-bit will appear. If the option Yes is selected
for this, both valves can move the same way, e.g. both to 50%. If the communication object is switched off again, the previous
state will be restored.
Telegram value:
0 = No function
1 = Parallel mode
