Device technology
FCA/S 1.x.x.1 | 2CDC508134D0202 57
All outputs can be controlled independently.
The following table provides an overview of the functions possible with the outputs of the Fan Coil Actuator
and the application:
Functions of the output
A
C
General
- Overload


- Parallel operation


Valve drives allocated to the Fan Coil unit
- Analog (0…10 V)


- 1 control value/1 valve

free
- 2 control values/1 valve

free
- 2 control values/2 valves


Setting facilities for valve drives
- Analog (0…10 V)
- Separate heating/cooling


- Direction
OPEN/CLOSE
OPEN/CLOSE
 = Function is supported
- = Function is not supported
free = Is available and can be used separately
Functions of the output
I
E
G
H
Switch function
Normally closed/ Normally open contact




Time
Staircase light




Fan
Level
1
2
3
-
 = Function is supported
- = Function is not supported
