ABB MicroFlex e150 Quick Installation Guide

10 Quick Installation Guide – MicroFlex e150
Technical data
 Fuses
Catalog
Number
Continuous
Output
Amps
(RMS)
AC
supply
type
Input Fuse
(A)
Circuit
breaker
(C-type)
Minimum
Wire Gauge
AWG mm
2
E152A03... 3A
1Φ
Ferraz Shawmut:
6x32 FA series, 10A (W084314P)
or
BS88 2.5 URGS 10A (N076648J)
10 A 14 2
3Φ
Ferraz Shawmut:
6x32 FA series, 8A (V084313P)
or
BS88 2.5 URGS, 7A (M076647J)
8A 14 2
E152A06... 6A
1Φ
Ferraz Shawmut:
6x32 FA series, 20A (A084318P)
or
BS88 2.5 URGS, 20A (L097507J)
20 A 14 2
3Φ
Ferraz Shawmut:
6x32 FA series, 12.5A (X084315P)
or
BS88 2.5 URGS, 12A (P076649J)
12.5 A 14 2
E152A09... 9A
1Φ
Ferraz Shawmut:
BS88 2.5 URGS, 25A (R076651J)
25 A 14 2.5
3Φ
Ferraz Shawmut:
6x32 FA series, 20A (A084318P)
or
BS88 2.5 URGS, 20A (L097507J)
20 A 14 2

ABB MicroFlex e150 Specifications

General

Brand	ABB
Model	MicroFlex e150
Category	Control Unit
Language	English
