PSS – The flexible range
Technical data
Rated insulation voltage U
i
690 V
Rated operational voltage U
e
208 ... 500 V AC, 400 ... 690 V AC + 10 % / -15 %, 50/60 Hz ±5 %
Rated control supply voltage U
s
110 ... 120 V or 220 ... 240 V +10 % / -15 %, 50/60 Hz ±5 %
Rated control circuit voltage U
c
Internal 24 V DC
Starting capacity at I
e
at max. rated current, I
e
4 x I
e
for 10 sec.
Number of starts per hour 30
1)
Overload capability
Overload class
10
Service factor PSS18/30 ... 250/430 PSS300/515
115 % 110 %
Ambient temperature
during operation -25 ºC to + 60 ºC
2)
during storage -40 ºC to + 70 ºC
Maximum altitude 4000 m
3)
Degree of protection PSS18/30-500 ... 44/76-500 PSS50/85-500 ... 72/124-500 PSS85/147-500 ... 300/515-500
Main circuit IP20 IP10 IP00
PSS18/30-690 ... 72/124-690 PSS85/147-690 ... 300/515-690
IP10 IP00
Supply and control circuit PSS18/30 ... PSS300/515
IP20
Signal relays
By-pass signal Yes
Fault signal Yes (NO or NC)
Rated operational voltage, U
e
250 V AC / 24 V DC
Rated thermal current I
e
5A
Rated operational current I
e
at AC-15 (U
e
=250 V)
1.5 A
Signaling indication LED
Ready to start / ON Green
Completed start ramp / T.O.R Green
General fault Red
External fault Red
Settings
Ramp time during start 1 – 30 sec
Ramp time during stop 0 – 30 sec
Initial voltage during start 30 – 70 %
Current limit function x CT-ratio 1.5 ... 4
4)
Switch for In-line / Inside Delta Yes
1)
Valid for 50 % on time and 50 % off time. If other data is required, contact your sales ofce.
2)
Above 40 ºC up to max. 60 ºC reduce the rated current with 0.8 % per ºC.
3)
When used at high alitudes above 1000 meters up to 4000 meters you need to derate the rated current using the following formula.
[ % of I
e
= 100 -
x - 1000
] x = actual altitude for the softstarter
150
4)
Only if current transformer is connected (accessory).
