To connect the PST Softstarter to a DeviceNet or CANopen eldbus system...
you need specic software for PLC set-up, (EDS le) which is available at www.abb.com/lowvoltage
on the Softstarter pages. Look under the documentation-link named Software. If you need help
or advice, please contact your local ABB ofce.
Black cable
DNP21-FBP
MRP21-FBP
COP21-FBP
50 Softstarters | 1SFC132005C0201, rev.F
FBP FieldBusPlug
DeviceNet, MODBUS-RTU and CANopen, ordering details
DeviceNet FieldBusPlug
Ready-made DeviceNet eldbus interface with various cable lengths.
• Applicable on all FBP motor starters and other devices
• Degree of protection IP65, diagnostic LED
Designation Cable length Type Order code
Pack
ing
piece
Weight
kg
1 piece
DeviceNet-FBP 0.25 m
DNP21-FBP.025 1SAJ 230 000 R1003
1 0.09
DeviceNet-FBP 0.50 m
DNP21-FBP.050 1SAJ 230 000 R1005
1 0.10
DeviceNet-FBP 1.00 m
DNP21-FBP.100 1SAJ 230 000 R1010
1 0.13
DeviceNet-FBP 5.00 m
DNP21-FBP.500 1SAJ 230 000 R1050
1 0.36
MODBUS-RTU FieldBusPlug
Ready-made MODBUS-RTU eldbus interface with various cable lengths.
• Applicable on all FBP motor starters and other devices
• Degree of protection IP65, diagnostic LED
Designation Cable length Type Order code
Pack
ing
piece
Weight
kg
1 piece
MODBUS-RTU-FBP 0.25 m MRP21-FBP.025 1SAJ 250 000 R0003 1 0.09
MODBUS-RTU-FBP 0.50 m MRP21-FBP.050 1SAJ 250 000 R0005 1 0.10
MODBUS-RTU-FBP 1.00 m MRP21-FBP.100 1SAJ 250 000 R0010 1 0.13
MODBUS-RTU-FBP 5.00 m MRP21-FBP.500 1SAJ 250 000 R0050 1 0.36
CANopen FieldBusPlug
Ready-made CANopen eldbus interface with various cable lengths.
• Applicable on all FBP motor starters and other devices
• Degree of protection IP65, diagnostic LED
Designation Cable length Type Order code
Pack
ing
piece
Weight
kg
1 piece
CANopen-FBP 0.25 m COP21-FBP.025 1SAJ 230 100 R1003 1 0.09
CANopen-FBP 0.50 m COP21-FBP.050 1SAJ 230 100 R1005 1 0.10
CANopen-FBP 1.00 m COP21-FBP.100 1SAJ 230 100 R1010 1 0.13
