ABB Relion 670 series User Manual

7.2 Logging off
GUID-0FDDB51B-D1C2-4442-AAE5-865BC39AE253 v1
The user is automatically logged of
f after the display timeout. The
IED returns to a
state where only reading is enabled. Manual logoff is also possible.
1.
Press
.
2.
T
o confirm logof
f, select Yes and press
.
IEC12000159-3-en.vsd
IEC12000159 V3 EN-US
Figure 71: Logging off
•
To cancel logoff, press
.
7.3 Saving settings
GUID-47AFC39B-6EE3-40BB-8EB7-FAFBD1120F5E v2
Editable values are stored in the nonvolatile flash memory
. Most of the parameter
changes take effect immediately after storing, but some parameter changes require
application restart. Values stored in the flash memory remain in effect also after
reboot.
1.
Press
to confirm any changes.
2.
Press to move upwards in the menu tree or to enter the Main Menu.
3.
T
o save the changes in nonvolatile memory
, select Yes and press
.
•
To exit without saving changes, select No and press .
•
To cancel saving settings, select Cancel and press .
Pressing Cancel in the Save changes dialog closes only the Save
changes dialog box, but the IED remains in the editing mode. All
the changes applied to any setting are not lost, and changing
settings can continue. To leave the change setting mode, select No
or
Yes in the Save changes dialog.
After changing the parameters marked with the exclamation mark
“!”, the IED restarts automatically for the changes to take effect.
Section 7 1MRK 511 399-UEN B
Local HMI use
88 670 series 2.2 IEC
Cyber security deployment guideline
