Channel ID text Level trigger mode
9 EFPADM3 - start Positive or Rising
WPWDE3 - start
10 INTRPTEF1 - start Positive or Rising
11 EFHPTOC1 - start Positive or Rising
12 PDNSPTOC1 - start Positive or Rising
13 T1PTTR1 - start Positive or Rising
14 PHPTOV1 - start Positive or Rising
15 PHPTOV2 - start Positive or Rising
16 PHPTOV3 - start Positive or Rising
17 PSPTUV1 - trret Positive or Rising
18 NSPTOV1 - trbu Positive or Rising
19 PHPTUV1 - start Positive or Rising
20 PHPTUV2 - start Positive or Rising
21 PHPTUV3 - start Positive or Rising
22 ROVPTOV1 - start Positive or Rising
23 ROVPTOV2 - start Positive or Rising
24 ROVPTOV3 - start Positive or Rising
25 CCBRBRF1 - trret Level trigger off
26 CCBRBRF1 - trbu Level trigger off
27 PHIPTOC1 - operate Level trigger off
DPHHPDOC1 - operate
DPHLPDOC1 - operate
DPHLPDOC2 - operate
28 NSPTOC1 - operate Level trigger off
NSPTOC2 - operate
29 DEFHPDEF1 - operate Level trigger off
DEFLPDEF1 - operate
DEFLPDEF2 - operate
EFPADM1 - operate
EFPADM2 - operate
EFPADM3 - operate
WPWDE1 - operate
WPWDE2 - operate
WPWDE3 - operate
30 INTRPTEF1 - operate Level trigger off
31 EFHPTOC1 - operate Level trigger off
32 PDNSPTOC1 - operate Level trigger off
33 INRPHAR1 - blk2h Level trigger off
34 T1PTTR1 - operate Level trigger off
Table continues on next page
1MRS756378 S Section 3
REF615 standard configurations
REF615 169
Application Manual

ABB relion REF615 Specifications

General

Type	Feeder Protection and Control Relay
Rated Frequency	50/60 Hz
Control Functions	Circuit breaker control, Disconnector control
Application	Feeder protection in utility and industrial power distribution systems
Communication Protocols	IEC 61850, Modbus, DNP3
Mounting	Flush mounting
Operating Temperature	-25°C to +55°C
Protection Functions	Overcurrent, earth fault, undervoltage, overvoltage
Weight	2.5 kg
