Section 3 REF615 standard configurations
3.1 Standard configurations
REF615 is available in twelve alternative standard configurations. The standard
signal configuration can be altered by means of the signal matrix or the graphical
application functionality of the Protection and Control IED Manager PCM600.
Further, the application configuration functionality of PCM600 supports the creation
of multi-layer logic functions using various logical elements, including timers and
flip-flops. By combining protection functions with logic function blocks, the relay
configuration can be adapted to user-specific application requirements.
The relay is delivered from the factory with default connections described in the
functional diagrams for binary inputs, binary outputs, function-to-function
connections and alarm LEDs. Some of the supported functions in REF615 must be
added with the Application Configuration tool to be available in the Signal Matrix tool
and in the relay. The positive measuring direction of directional protection functions
is towards the outgoing feeder.
Table 9: Standard configurations
Description
Std. conf.
Non-directional overcurrent and directional earth-fault protection A
Non-directional overcurrent and directional earth-fault protection and circuit-breaker condition
monitoring (RTD option) B
Non-directional overcurrent and earth-fault protection C
Non-directional overcurrent and earth-fault protection and circuit-breaker condition monitoring (RTD
option) D
Non-directional overcurrent and directional earth-fault protection, voltage-based measurements and
circuit-breaker condition monitoring (RTD option) E
Directional overcurrent and earth-fault protection, voltage-based protection and measurements, and
circuit-breaker condition monitoring (RTD option) F
Directional overcurrent and earth-fault protection, voltage-based protection and measurements, and
circuit-breaker condition monitoring (sensor inputs and optional synchro-check with IEC 61850-9-2
LE)
G
Non-directional overcurrent and earth-fault protection, voltage and frequency based protection and
measurements, synchro-check and circuit-breaker condition monitoring (RTD option) H
Directional overcurrent and earth-fault protection, voltage and frequency based protection and
measurements, synchro-check and circuit-breaker condition monitoring (optional power quality and
RTD option)
J
Table continues on next page
1MRS756378 S Section 3
REF615 standard configurations
REF615 37
Application Manual
