ABB relion REF615 User Manual

3.9.2.2 Default disturbance recorder settings
Table 44: Default disturbance recorder analog channels
Channel
Description
1 IL1
2 IL2
3 IL3
4 Io
5 U1
6 U2
7 U3
8 -
9 -
10 -
11 -
12 -
Table 45: Default disturbance recorder binary channels
Channel
ID text Level trigger mode
1 DPHLPDOC1 - start Positive or Rising
2 DPHLPDOC2 - start Positive or Rising
3 DPHHPDOC1 - start Positive or Rising
4 PHIPTOC1 - start Positive or Rising
5 NSPTOC1 - start Positive or Rising
6 NSPTOC2 - start Positive or Rising
7 DEFLPDEF1 - start Positive or Rising
EFPADM1 - start
WPWDE1 - start
8 DEFLPDEF2 - start Positive or Rising
EFPADM2 - start
WPWDE2 - start
9 EFPADM3 - start Positive or Rising
WPWDE3 - start
10 EFHPTOC1 - start Positive or Rising
11 PDNSPTOC1 - start Positive or Rising
12 T1PTTR1 - start Positive or Rising
13 PHPTOV1 - start Positive or Rising
14 PHPTOV2 - start Positive or Rising
15 PHPTOV3 - start Positive or Rising
16 PSPTUV1 - trret Positive or Rising
Table continues on next page
Section 3 1MRS756378 S
REF615 standard configurations
200 REF615
Application Manual

ABB relion REF615 Specifications

General

Type	Feeder Protection and Control Relay
Rated Frequency	50/60 Hz
Control Functions	Circuit breaker control, Disconnector control
Application	Feeder protection in utility and industrial power distribution systems
Communication Protocols	IEC 61850, Modbus, DNP3
Mounting	Flush mounting
Operating Temperature	-25°C to +55°C
Protection Functions	Overcurrent, earth fault, undervoltage, overvoltage
Weight	2.5 kg
