ABB relion REF615 User Manual

Table 15: Default disturbance recorder binary channels
Channel ID text Level trigger mode
1 PHLPTOC1 - start Positive or Rising
2 PHHPTOC1 - start Positive or Rising
3 PHHPTOC2 - start Positive or Rising
4 PHIPTOC1 - start Positive or Rising
5 NSPTOC1 - start Positive or Rising
6 NSPTOC2 - start Positive or Rising
7 DEFLPDEF1 - start Positive or Rising
EFPADM1 - start
WPWDE1 - start
8 DEFLPDEF2 - start Positive or Rising
EFPADM2 - start
WPWDE2 - start
9 EFPADM3 - start Positive or Rising
WPWDE3 - start
10 INTRPTEF1 - start Positive or Rising
11 EFHPTOC1 - start Positive or Rising
12 PDNSPTOC1 - start Positive or Rising
13 T1PTTR1 - start Positive or Rising
14 ROVPTOV1 - start Positive or Rising
15 ROVPTOV2 - start Positive or Rising
16 ROVPTOV3 - start Positive or Rising
17 CCBRBRF1 - trret Level trigger off
18 CCBRBRF1 - trbu Level trigger off
19 PHIPTOC1 - operate Level trigger off
PHHPTOC1 - operate
PHHPTOC2 - operate
PHLPTOC1 - operate
20 NSPTOC1 - operate Level trigger off
NSPTOC2 - operate
21 DEFHPDEF1 - operate Level trigger off
DEFLPDEF1 - operate
DEFLPDEF2 - operate
EFPADM1 - operate
EFPADM2 - operate
EFPADM3 - operate
WPWDE1- operate
WPWDE2 - operate
WPWDE3 - operate
Table continues on next page
Section 3 1MRS756378 S
REF615 standard configurations
52 REF615
Application Manual

ABB relion REF615 Specifications

General

Type	Feeder Protection and Control Relay
Rated Frequency	50/60 Hz
Control Functions	Circuit breaker control, Disconnector control
Application	Feeder protection in utility and industrial power distribution systems
Communication Protocols	IEC 61850, Modbus, DNP3
Mounting	Flush mounting
Operating Temperature	-25°C to +55°C
Protection Functions	Overcurrent, earth fault, undervoltage, overvoltage
Weight	2.5 kg
