ABB relion REF615 User Manual

Channel ID text Level trigger mode
11 EFHPTOC1 - start Positive or Rising
12 PDNSPTOC1 - start Positive or Rising
13 T1PTTR1 - start Positive or Rising
14 ROVPTOV1 - start Positive or Rising
15 ROVPTOV2 - start Positive or Rising
16 ROVPTOV3 - start Positive or Rising
17 CCBRBRF1 - trret Level trigger off
18 CCBRBRF1 - trbu Level trigger off
19 PHIPTOC1 - operate Level trigger off
PHHPTOC1 - operate
PHHPTOC2 - operate
PHLPTOC1 - operate
20 NSPTOC1 - operate Level trigger off
NSPTOC2 - operate
21 DEFHPDEF1 - operate Level trigger off
DEFLPDEF1 - operate
DEFLPDEF2 - operate
EFPADM1 - operate
EFPADM2 - operate
EFPADM3 - operate
WPWDE1 - operate
WPWDE2 - operate
WPWDE3 - operate
22 INTRPTEF1 - operate Level trigger off
23 EFHPTOC1 - operate Level trigger off
24 PDNSPTOC1 - operate Level trigger off
25 INRPHAR1 - blk2h Level trigger off
26 T1PTTR1 - operate Level trigger off
27 ROVPTOV1 - operate Level trigger off
ROVPTOV2 - operate
ROVPTOV3 - operate
28 ARCSARC1 - ARC flt det Level trigger off
ARCSARC2 - ARC flt det
ARCSARC3 - ARC flt det
29 ARCSARC1 - operate Positive or Rising
30 ARCSARC2 - operate Positive or Rising
31 ARCSARC3 - operate Positive or Rising
32 DARREC1 - inpro Level trigger off
33 DARREC1 - close CB Level trigger off
Table continues on next page
1MRS756378 S Section 3
REF615 standard configurations
REF615 75
Application Manual

ABB relion REF615 Specifications

General

Type	Feeder Protection and Control Relay
Rated Frequency	50/60 Hz
Control Functions	Circuit breaker control, Disconnector control
Application	Feeder protection in utility and industrial power distribution systems
Communication Protocols	IEC 61850, Modbus, DNP3
Mounting	Flush mounting
Operating Temperature	-25°C to +55°C
Protection Functions	Overcurrent, earth fault, undervoltage, overvoltage
Weight	2.5 kg
