5.11 Showing parameters
Some function blocks have a function-specific ON/OFF setting. When the function
setting is "off", all settings are hidden and when the function setting is "on", all
settings are visible based on the other visibility and hiding rules.
Switch a function block on or off via the Operation parameter under the
function block.
The values "Basic" or "Advanced" of the Setting visibility parameter in
Configuration> HMI have no effect on the Parameter List page. This
page has its own Basic settings option which can be used to hide or
show the advanced settings on the Parameter List page.
1. Select Import/Export on the menu bar.
2. Select Parameter List from the drop-down list.
Figure 60: Displaying parameters
3.
Click the filter icon
.
4. In the Apply filter dialog, select the settings that should be shown and click
Apply. If nothing is selected, all settings are shown.
1MRS759118 D
Using Web HMI
REX640
Operation Manual
71

ABB RELION REX640 Specifications

General

Model	RELION REX640
Category	Protection Device
Communication Protocols	IEC 61850, Modbus, DNP3, IEC 60870-5-103
Display	LCD
Rated Voltage	100-240 V AC/DC
Rated Frequency	50/60 Hz
Protection Functions	Overcurrent, Earth Fault, Overvoltage, Undervoltage, Frequency
Mounting	Rack mounting
Inputs/Outputs	Analog inputs
Housing	Metal
Input Voltage	24-250 V DC / 100-240 V AC
Operating Temperature	-25°C to +70°C
Enclosure	IP20
