ABB RELION REX640 User Manual

Fault indication
Fault
code
Additional
information
Fast self-
recovery
attempt
Slow 10min
self-
recovery
(# of
attempts)
Immediate
IRF-mode
Action in permanent fault
state
change the hardware mod-
ule in slot A1.
Internal Fault
Card error, Slot
C
-40 Card in slot C is
faulty.
Yes No Yes Exchange the hardware
module in slot C.
Internal Fault
Card error, Slot
E
-41 Card in slot E is
faulty.
Yes No Yes Exchange the hardware
module in slot E.
Internal Fault
Card error, Slot
A2
-42 Card in slot A2 is
faulty.
Yes No Yes Exchange the communica-
tion module in slot A2.
Internal Fault
Card error, Slot
B
-43 Card in slot B is
faulty.
Yes No Yes Exchange the hardware
module in slot B.
Internal Fault
Card error, Slot
D
-44 Card in slot D is
faulty.
Yes No Yes Exchange the hardware
module in slot D.
Internal Fault
Card error, Slot
F
-45 Card in slot F is
faulty.
Yes No Yes Exchange the hardware
module in slot F.
Internal Fault
Card error, Slot
G
-46 Card in slot G is
faulty.
Yes No Yes Exchange the hardware
module in slot G.
Internal Fault
Card error, Slot
A1
-47 Card in slot A1 is
faulty.
Yes No Yes Exchange the hardware
module in slot A1.
Internal Fault
640-Prod. Li-
cense error
-62 Runtime error:
Product license er-
ror, license file is
not found or is
wrong
No No Yes If SW update under Modifi-
cation Sales has been car-
ried out, redo the update. If
not recovered, contact your
nearest ABB representative
to check the next possible
corrective action.
Troubleshooting 1MRS759118 D
98 REX640
Operation Manual

ABB RELION REX640 Specifications

General

Model	RELION REX640
Category	Protection Device
Communication Protocols	IEC 61850, Modbus, DNP3, IEC 60870-5-103
Display	LCD
Rated Voltage	100-240 V AC/DC
Rated Frequency	50/60 Hz
Protection Functions	Overcurrent, Earth Fault, Overvoltage, Undervoltage, Frequency
Mounting	Rack mounting
Inputs/Outputs	Analog inputs
Housing	Metal
Input Voltage	24-250 V DC / 100-240 V AC
Operating Temperature	-25°C to +70°C
Enclosure	IP20
