Table 229. Arc sensors
Item Order number
ARC lens sensor cable 1.5 m 2RCA040290A0001
ARC lens sensor cable 3 m 2RCA040290A0003
ARC lens sensor cable 5 m 2RCA040290A0005
ARC lens sensor cable 7.5 m 2RCA040290A0007
ARC lens sensor cable 15 m 2RCA040290A0015
ARC loop sensor cable 5 m 2RCA041050A0005
ARC loop sensor cable 10 m 2RCA041050A0010
ARC loop sensor cable 15 m 2RCA041050A0015
ARC loop sensor cable 20 m 2RCA041050A0020
ARC loop sensor cable 25 m 2RCA041050A0025
ARC loop sensor cable 30 m 2RCA041050A0030
ARC loop sensor cable 40 m 2RCA041050A0040
ARC loop sensor cable 50 m 2RCA041050A0050
ARC loop sensor cable 60 m 2RCA041050A0060
Table 230. Connectors
Item
Order number
Compression type signal connectors SYJ-ZRK 2Z18P1
Ring lug type signal connectors SYJ-ZRK 33X18
Push-in type signal connectors SYJ-ZRK 53P18PM
1 CT-1 VT compression type connector 2RCA040474A0004
5 CT compression type connector 2RCA040474A0001
5 VT compression type connector 2RCA040474A0002
1 CT-4 VT compression type connector 2RCA040474A0003
1 CT-1 VT ring lug type connector 2RCA041297A0004
5 CT ring lug type connector 2RCA041297A0001
5 VT ring lug type connector 2RCA041297A0002
1 CT-4 VT ring lug type connector 2RCA041297A0003
RS-485/IRIG-B connector SYJ-ZRK 44P10
27. Tools
The protection relay is delivered with the correct protection and
control functionality included but it needs some engineering to
fit in the needed application. The default parameter setting
values can be changed from the LHMI, the Web browser-based
user interface (Web HMI) or Protection and Control IED
Manager PCM600 in combination with the relay-specific
connectivity package.
PCM600 offers extensive relay configuration functions. For
example, the setting parameters, relay application, graphical
display and IEC 61850 communication, including horizontal
GOOSE communication, can be modified with PCM600.
The REX640 relay's LHMI pages can be customized and shared
between devices with a dedicated Display Editor which offers
intuitive graphical drawing tools with editable symbols for
single-line diagrams. In addition, it is possible to create
personalized views for every supported application. The page
1MRS759144 A
REX640
Product version: 1
102 ABB

ABB REX640 Specifications

General

Device Type	Protection Relay
Communication Protocols	IEC 61850, Modbus, DNP3, IEC 60870-5-103
Rated Frequency	50/60 Hz
Operating Temperature Range	-25°C to +55°C
Display	LCD
Housing	Metal
Manufacturer	ABB
Model	REX640
Mounting	Rack mounting
Inputs and Outputs	Configurable binary inputs and outputs
Rated Voltage	48-240 V AC/DC
Protection Functions	Overcurrent, Earth Fault
Input Voltage	48-240 V AC/DC
Certifications	CE, UL, IEC
