Table 2. Module description
Module Description
ARC1001 4 × ARC sensor inputs (lense, loop or mixed)
COM1001
1 × RJ-45 (LHMI port) + 3 × RJ-45 + 1 × LD-SFP
1)
COM1002 1 × RJ-45 (LHMI port) + 2 × LC + 1 × RJ-45 + 1 × LD-SFP
COM1003 1 × RJ-45 (LHMI port) + 3 × LC + 1 × LD-SFP
COM1004 1 × RJ-45 (LHMI port) + 2 × RJ-45 + 1 × LD-SFP + 1 × RS-485/IRIG-B + 1 × FO UART
COM1005 1 × RJ-45 (LHMI port) + 2 × LC + 1 × LD-SFP + 1 × RS-485/IRIG-B + 1 × FO UART
BIO1001/
BIO1003
14 × BI + 8 × SO
BIO1002/
BIO1004
6 × SPO + 2 × SPO (TCS) + 9 × BI
RTD1001 10 × RTD channels + 2 × mA channels (input/output)
AIM1001 4 × CT + 1 × CT (sensitive, for residual current only) + 5 × VT
AIM1002 6 × CT + 4 × VT
SIM1001 3 × combi sensor inputs + 1 × CT (sensitive, for residual current only) + 1 × VT
PSM1001 24...60 VDC, 3 × PO (TCS) + 2 × PO + 3 × SO + 2 × SSO
PSM1002 48...250 VDC / 100...240 VAC, 3 × PO (TCS) + 2 × PO + 3 × SO + 2 × SSO
PSM1003 110/125 VDC (77...150 VDC), 3 × PO (TCS) + 2 × PO + 3 × SO + 2 × SSO
PO = Power Output
SO = Signal Output
SPO = Static Power Output
SSO = Static Signal Output
1) Line distance/line differential protection communication + binary signal transfer, optical multimode or single-mode LC small form-factor pluggable transceiver (SFP)
The relay has a nonvolatile memory which does not need any
periodical maintenance. The nonvolatile memory stores all
events, recordings and logs to a memory which retains data if
the relay loses its auxiliary supply.
1MRS759144 A
