Table 235. Base and optional functionality

IEC 61850 Pcs Base APP

APP

ADD

Protection

DSTPDIS 1 ●

DSTPLAL 1 ●

DSOCPSCH 1 ●

CRWPSCH 1 ●

RESCPSCH 1 ●

RCRWPSCH 1 ●

LNPLDF 1 ●

BSTGAPC 2 ● ●

CVPSOF 1 ●

PHLPTOC 3 ●

PHHPTOC 3 ●

PHIPTOC 3 ●

DPHLPDOC 3 ●

DPHHPDOC 3 ●

EFLPTOC 3 ●

EFHPTOC 3 ●

EFIPTOC 3 ●

DEFLPDEF 4 ●

DEFHPDEF 4 ●

DPSRDIR 2 ●

DNZSRDIR 2 ●

EFPADM 3 ●

MFADPSDE 3 ●

WPWDE 3 ●

INTRPTEF 1 ●

HAEFPTOC 1 ●

NSPTOC 3 ●

PDNSPTOC 1 ●

ROVPTOV 4 ●

PHPTUV 4 ●

PHVPTOV 2 ●

PHPTOV 4 ●

PSPTOV 4 ●

PSPTUV 4 ●

NSPTOV 4 ●

FRPFRQ 12 ●

PHPVOC 2 ●

OEPVPH 2 ● ●

T1PTTR 1 ●

T2PTTR 1 ● ●

COLPTOC 1 ●

CUBPTOC 3 ●

HCUBPTOC 2 ●

SRCPTOC 1 ●

CNUPTOV 2 ●

DNSPDOC 2 ●

LVRTPTUV 3 ●

VVSPPAM 1 ●

DQPTUV 2 ●

DOPPDPR 3 ● ● ●

DUPPDPR 3 ● ●

UZPDIS 2 ● ●

UEXPDIS 2 ●

1MRS759144 A

REX640

Product version: 1

122 ABB
