ABB REX640 User Manual

Table 189. Petersen coil controller (PASANCR) main settings
Parameter Function Value (Range) Step
Compensation mode PASANCR 1 = Absolute
2 = Relative
-
Detuning level PASANCR -100...100 A 1
Detuning level Rl PASANCR -100.0...100.0% 0.1
Tuning delay PASANCR 0...3600 s 1
V Res variation PASANCR 0.1...100.0 %U
n
0.1
Tuning mode PASANCR 1 = Coil movement
2 = Resistor switching
-
V Res EF level PASANCR 0.00...100.00 %U
n
0.01
EF mode PASANCR 1 = Blocked during EF
2 = Resonance
3 = Tuning during EF
-
Resistor healthy St PASANCR 0 = Off
1 = On
-
Resistor repeats PASANCR 0...100 1
Resistor pause PASANCR 0...100000000 ms 1
Coil V Nom PASANCR 0...400000 V 1
Fix coil V Nom PASANCR 0...400000 V 1
Auxiliary Wnd V Nom PASANCR 0...10000 V 1
Controller mode PASANCR 0 = Manual
1 = Automatic
-
Parallel resistor PASANCR 0 = False
1 = True
-
R0Transformer PASANCR 0...100 Ω 1
X0Transformer PASANCR 0...100 Ω 1
Voltage measurement PASANCR 1 = Busbar
2 = Coil
-
Resistor control PASANCR 1 = OFF
2 = ON
3 = Automatic
-
Resistor Nom value PASANCR 0.00...100.00 Ω 0.01
Fix coil value PASANCR 0...10000 A 1
Fix coil type PASANCR 1 = OFF
2 = ON
3 = Automatic
-
1MRS759144 A
REX640
Product version: 1
90 ABB

ABB REX640 Specifications

General

Device Type	Protection Relay
Communication Protocols	IEC 61850, Modbus, DNP3, IEC 60870-5-103
Rated Frequency	50/60 Hz
Operating Temperature Range	-25°C to +55°C
Display	LCD
Housing	Metal
Manufacturer	ABB
Model	REX640
Mounting	Rack mounting
Inputs and Outputs	Configurable binary inputs and outputs
Rated Voltage	48-240 V AC/DC
Protection Functions	Overcurrent, Earth Fault
Input Voltage	48-240 V AC/DC
Certifications	CE, UL, IEC
