Table 220. Voltage unbalance (VSQVUB)

Characteristic Value

Operation accuracy ±1.5% of the set value or ±0.002 × U

Reset ratio Typically 0.96

Table 221. Voltage unbalance (VSQVUB) main settings

Parameter Function Value (Range) Step

Operation VSQVUB 1 = on

5 = off

Unb detection method VSQVUB 1 = Neg Seq

2 = Zero Seq

3 = Neg to Pos Seq

4 = Zero to Pos Seq

5 = Ph vectors Comp

1MRS759144 A

REX640

Product version: 1

ABB 97
