Table 100. Three-phase overload protection for shunt capacitor banks (COLPTOC)
Characteristic Value
Operation accuracy Depending on the frequency of the measured current: f
n
±2 Hz, and no
harmonics
5% of the set value or 0.002 × I
n
Start time for overload stage
1)2)
Typically 75 ms
Start time for under current stage
2)3)
Typically 26 ms
Reset time for overload and alarm stage Typically 60 ms
Reset ratio Typically 0.96
Operate time accuracy in definite time mode 1% of the set value or ±20 ms
Operate time accuracy in inverse time mode 10% of the theoretical value or ±20 ms
Suppression of harmonics for under current stage DFT: -50 dB at f = n × f
n
, where n = 2,3,4,5,..
1) Harmonics current before fault = 0.5 × I
n
, harmonics fault current 1.5 × Start value , results based on statistical distribution of 1000 measurements
2) Includes the delay of the signal output contact
3) Harmonics current before fault = 1.2 × I
n
, harmonics fault current 0.8 × Start value , results based on statistical distribution of 1000 measurements
Table 101. Three-phase overload protection for shunt capacitor banks (COLPTOC) main settings
Parameter
Function Value (Range) Step
Start value overload COLPTOC 0.30...1.50 × I
n
0.01
Alarm start value COLPTOC 80...120% 1
Start value Un Cur COLPTOC 0.10...0.70 × I
n
0.01
Time multiplier COLPTOC 0.05...2.00 0.01
Alarm delay time COLPTOC 500...6000000 ms 100
Un Cur delay time COLPTOC 100...120000 ms 100
Table 102. Current unbalance protection for shunt capacitor banks (CUBPTOC)
Characteristic
Value
Operation accuracy Depending on the frequency of the measured current: f
n
±2 Hz
1.5% of the set value or 0.002 × I
n
Start time
1)2)
Typically 26 ms
Reset time Typically 40 ms
Reset ratio Typically 0.96
Operate time accuracy in definite time mode 1% of the theoretical value or ±20 ms
Operate time accuracy in inverse definite minimum time mode 5% of the theoretical value or ±20 ms
Suppression of harmonics DFT: -50 dB at f = n × f
n
, where n = 2,3,4,5,..
1) Fundamental frequency current = 1.0 × I
n
, current before fault = 0.0 × I
n
, fault current = 2.0 × Start value , results based on statistical distribution of 1000 measurements
2) Includes the delay of the signal output contact
1MRS759144 A
REX640
Product version: 1
ABB 61
