50 TTH300 HEAD-MOUNT TEMPERATURE TRANSMITTER | OI/TTH300-EN REV. E
… 11 Operation
… Parameter description PROFIBUS PA® and FOUNDATION Fieldbus®
Menu: Device Info
Menu / parameter Description
… / Device Info
Device ID Displays device ID
Serial Number Displays serial number
Software Version Displays software version
Hardware Version Displays hardware version
TAG Displays measuring point tagging
Description Displays a user-defined text
Operation Time Displays operating hours
Menu: Communication
Menu / parameter Description
… / Communication
TAG Measuring point tagging
• 16 characters
Bus Address Address range during bus operation
Value range: 0 to 125
Ident Number PROFIBUS PA profile: selects ID numbers than can be used
Manufacturer-specific: (IDENT__NUMBER_SELECT) only for PROFIBUS PA
Ident Number Profile ID numbers used for profile with PROFIBUS PA
• 1*AI (0x9700)
• 2*AI (0x9701)
• 3*AI (0x9702)
• 4*AI (0x9703)

ABB TTH300 Series Specifications

General

Type	Temperature transmitter
Display	Optional LCD display
Input	RTD, Thermocouple, Resistance
Output	4-20 mA, HART
Accuracy	±0.1% of span
Ambient temperature	-40°C to +85°C (-40°F to +185°F)
Housing material	Aluminum, Stainless steel
Communication	HART
Configuration	Via HART protocol, configuration tools
Power supply	10.5 ... 45 V DC (depending on version and load)
Measurement Range	Depends on sensor type (RTD, Thermocouple, etc.)
Protection Rating	IP66
Sensor Type	RTD, Thermocouple
