ABB UNO-DM-4.0-TL-PLUS User Manual

- 110 -
000697BG
7 - Operation
Specifications on operation of the LEDs
In correspondence to each status of the inverter indicated by the constant
or intermittent lighting of the specic LED, the display
07
also shows
a message identifying the operation which is being carried out or the
defect/anomaly recorded (see specic chapter).
In the case of malfunction it is extremely dangerous to intervene personally to try and eliminate
the defect. The instructions below must be followed scrupulously; if you do not have the
necessary experience and training to intervene safely, please contact a specialist.
LED insulation fault
Interventions after warning of insulation fault
When the GFI LED comes on, rst try to reset the warning by pressing
the multi-function ESC button on the keyboard
08
.
Should the inverter reconnect normally to the grid, the fault was due to
temporary phenomena.
You are advised to have the plant inspected by the installer or a specialist should this
malfunction occur repeatedly.
Should the inverter not reconnect to the grid, isolate it on both the AC and
DC sides (by using the disconnect switches), then contact the installer or
authorised centre to repair the fault in the photovoltaic generator.
COMM, WLAN LEDs behaviour
The following table shows all the possible status of “COMM” and “WLAN”
LEDs on the LED panel
06
according to the operating status of the
wireless board.
LED Description
COMM
(MULTICOLOR)
Operation status of wireless communication line:
Blink Red: Communication error (no communication available)
Green: Communication OK
WLAN
(MULTICOLOR)
Communication type and quality of the wireless communication signal (for
“Station Mode”):
Blink Blue: Wireless board is working in Access Point mode (AP Mode)
OFF: No signal
Blink Red: Low signal strenght
Blink Yellow: Medium signal strenght
Blink Green: High signal strenght
