- 93 -
000694AG
5 - Installation
Closing the front cover
At the end of the inverter connection and conguration stage and be-
fore proceeding with the commissioning, the inverter's cover
05
must be
closed.
During the installation of the cover, the installation sequence must be respected as well as
the tightening torque of the 8 screws (set out in the paragraph on technical data) in order to
keep the IP level of the inverter unchanged
• Insert and screw in the 8 xing screws.
• Tighten the screws respecting the sequence and the tightening torque.
After having installed the front cover, it is possible to proceed with the
commissioning of the inverter.
IP65
1
8
6
5
7
3
2
4
