E-PGM+ / E-GANG4/6 / E-PGM Serial User’s Manual 2. Hardware
7
2 Hardware
2.1 Specifications
The E-PGM+ and E-GANG4/GANG6 have similar features, but the E-PGM Serial has different
features. The E-PGM Serial was designed only for On-board Programming purpose and features
Noise Robust for the mass production environment.
Specifications of each Programmer equipment are compared in Table 1.
Table 1. Programmer Specifications
E-PGM+
E-PGM Serial
E-GANG4
E-GANG6
Type
Standalone Type Universal Programmer
Dimension [Cm]
8.3 X 14.5 X 3.3
8.3 X 14.5 X 3.3
33.5 X 23 X 4.3
48.2 X 23 X 4.3
Weight [g]
350
330
2,000
2,800
Power Source
External DC 15V Power Supply
Input Voltage
15V/1A
15V/1A
15V/2A
15V/2A
Power Consumption
15W
15W
30W
30W
Operating Temp.
-10℃ ~ 40℃
Storage Temp.
-30℃ ~ 80℃
Functions of each Programmer equipment are compared in Table 2.
Table 2. Programmer Functions
E-PGM+
E-PGM Serial
E-GANG4/6
40-DIP Socket
O
X
O
ISP Port
O
O
O
ISP Port ESD/
EOS/
Surge Protection
O
Level shifter added
VDD Protection Diode added
O
Supported Devices
All Devices
94/95/96/97XXXX series
(except for 97F1104S/1204S/1316S)
All 32-bit MCU
All Devices
Buffer Size
1MB
8MB
1MB
Read Button
Joystick Button
Push Button
Joystick Button
Support Barcode
Reader (RS-232C)
O
X
X
Handler Interface
O
O
O
Operating S/W
E-PGM+.exe
E-PGM+.exe
E-PGM+.exe
