Acer Aspire One D270 Series User Manual

Machine Maintenance Procedures 3-27
Thermal Module Installation 0
IMPORTANT:
+
Apply approved thermal grease and ensure all heat pads are in position
before replacing module.
CAUTION:
!
Use caution when applying thermal grease. Thermal grease may cause
damage to the mainboard.
The following thermal grease types are approved for use:
Silmore GP50
Honeywell
Jet Motor 7762
The following thermal pads are approved for use:
Eapus XR-PE
1. Remove all traces of thermal grease from CPU using a lint-free cloth or cotton swab
and Isopropyl Alcohol, Acetone, or other approved cleaning agent.
2. Apply small amount of thermal grease to center of CPU.
NOTE:
NOTE:
Force used during installation of thermal module is sufficient to spread grease
evenly over CPU top.
3. Place the thermal module on the mainboard. Refre to Figure 3-26.
4. Install and secure two (2) screws (C) to the mainboard in numerical order from one (1)
to two (2). Refer to Figure 3-25.
5. Connect thermal module cable (A) to mainboard connector (B). Refer to Figure 3-25.
6. Install mainboard.
ID Size Quantity Screw Type
C M2.0*3.0 NI 2
