3-36 Machine Maintenance Procedures

LCD Panel Removal 0

Prerequisite:

LCD Bezel Removal

1. Find the camera module (C) on the LCD module. Refer to Figure 3-33.

2. Disconnect the camera cable (A) from the connector (B) (Figure 3-36).

Figure 3-36. Camera Disconnect

3. Remove the four (4) screws (D) (Figure 3-37).

Figure 3-37. LCD Panel Screws
