Acer Aspire One D270 Series User Manual

Hardware Specifications and Configurations 1-35
Audio Codec and Amplifier
Item Specification
Audio
Controller
Realtek ALC271X
Features
 Meets WLP (Windows Logo Program) requirements for Windows XP,
Vista and Windows 7
 98dB Signal-to-Noise Ratio (A-weighting) for DAC output
 90dB Signal-to-Noise Ratio (A-weighting) for ADC output
 4-channel DAC supports 16/20/24-bit PCM format for indepent two
stereo channel or 2.1 audio playback
 4-channel ADC supports 16/20/24-bit PCM format for indepent two
stereo channel audio inputs
 All DACs support 44.1k/48k/96k/192kHz sample rate
 All ADCs support 44.1k/48k/96k/192kHz sample rate
 S/PDIF-OUT support 16/20/24-bit format and 44.1/48/88.2/96/192kHz
rate
 Supports MONO line level output
 Supports external PCBEEP input and built-in digital BEEP generator
 Software selectable 2.5V/3.2V VREFOUT as bias voltage for analog
microphone input
 Programmable +12/+24/+36dB boot gain for analog microphone input
 Supports stereo digital microphone input
 Programmable boost gain and volume control for digital microphone
input
 Built-in headphone amplifiers for port-C (LINE1) and port-I(HP OUT)
 Headphone amplifier for port-I does not require DC blocking
capacitors
 Two jack detection pins each designed to detect up to 4 jacks, and
S/PDIF-OUT jack detection is supported
 EAPD (External Amplifier Power Down) is supported
 Supports Anti-pop mode when analog power AVDD is on and digital
power is off
 Power support: 3.3V digital core power: 1.5V~3.3V digital IO power for
HDA link; 3.0V~5.5V analog power; 4.5V~5.5V power stage voltage
 Enhanced power management features for normal operation and
standby mode
 Stereo Bridge-Tied Load Class-D amplifier at port-D has 2Watt (rms)/4
Ohms per channel output
 Short circuit and thermal overload protection for Class-D amplifier
 Class D amplifier has high pass filter with programmable Cut-Off
frequency (10Hz~900Hz) to prevent low frequency signal damage
speaker
 Class D amplifier output with slew rate and spread spectrum control to
improve EMI performance
 Independent left and right channel of output power limiter
(25%~100% power range) to protect speaker
http://mycomp.su - Maintenance and Service Guide,Service Manual,Motherboard Schematics for Laptop/notebook
Ремонт ноутбуков.Запчасти и комплектующие для ноутбука. Схемы,сервис мануалы,инструкции по разборке ноутбука.

Acer Aspire One D270 Series Specifications

General

Graphics	Intel GMA 3600
RAM	1GB or 2GB DDR3
Weight	1.3 kg (2.87 lbs)
Webcam	0.3 MP
Card Reader	Multi-in-1 card reader
Processor	Intel Atom N2600
Display	10.1-inch, 1024 x 600 resolution
Storage	320GB HDD
Operating System	Windows 7 Starter
Battery	6-cell Li-ion
Wireless	Wi-Fi 802.11b/g/n
Ports	3 x USB 2.0, VGA, HDMI
