Agilent Technologies 54831A User Manual

Setting Up the Oscilloscope
To tilt the oscilloscope upward for easier viewing
1-27
To tilt the oscilloscope upward for easier viewing
1 Lift up the front of the oscilloscope, grasp the wire bail near the center,
and pull it down and forward until it latches into place.
Figure 1-21
Latching the Oscilloscope Front Feet
