Using the Oscilloscope
To set the oscilloscope to a known starting condition
3-7
To set the oscilloscope to a known starting condition
• Press the Default Setup key.
You can set up the oscilloscope for many different kinds of complex
measurements. To easily reset the oscilloscope to a known measurement
configuration, use the Default Setup key.
If you use the Default Setup key with the graphical interface enabled, you can
select Undo Default Setup from the Control menu to return the oscilloscope to
its original configuration.
Save the Current Oscilloscope Configuration
Before using Default Setup, you may want to save the current oscilloscope
configuration for later use. See the built-in information system (described in chapter
4) for instructions on saving and recalling setups, and for information on the exact
configuration that is set when you press Default Setup.
