58
6063B
"CAL 1" ! turn calibration mode on
"CAL:INIT 240,60" ! initialize default calibration parameters
"CAL:SAVE" ! store calibration constants in EEROM
"DIAG:CAL 0,6063" ! model number
"DIAG:CAL 1,16901" ! model number suffix and GP-IB address 5
"DIAG:CAL 2l,0" ! initial *SRE value
"DIAG:CAL 22,0" ! initial *ESE value
"DIAG:CAL 23,1" ! initial *PSE value
"DIAG:CAL 26,1" ! module width ( 6063 = 1 CHANNEL )
"DIAG:CAL 27,1" ! module type
"DIAG:CAL 28,5000" ! voltage for soft over power
"DIAG:CAL 29,5200" ! current for soft over power
"*RST" ! reset factory default state
"CURR:SLEW 0.167E6" ! turn on slew rate
"*SAV 0" ! to location 0
"CAL 0" ! turn calibration mode off
Disassembly Procedures
The following disassembly procedures are listed in alphabetical order. Before proceeding with any disassembly, disconnect
the ac power cord, remove the four cover screws, and remove the cover. Then proceed to the applicable disassembly
procedure.
Refer to Figure 5-1 for the location of the Electronic Load's mechanical components.
AC Receptacle
1. Record the color code and location of each wire connected to the ac receptacle.
2. Disconnect the push-on connectors from the receptacle terminals.
3. Unsolder the ground wire.
4. Release the locking tabs by pressing them inward against the body of the receptacle and remove the receptacle.
Fan
1. Remove the six screws securing heatsink cover and remove heatsink cover.
2. Disconnect the fan cable from J554.
3. Remove the two screws securing the fan to the main heat sinks and remove the fan.
