Introduction
Scope
This manual contains information for troubleshooting and repairing the Agilent Technologies 6060B and 6063B Electronic
Load to the component level. Replaceable parts lists and circuit diagrams are also provided. Verification procedures are
included to aid in determining the performance level either before or after repair. Calibration procedures and specifications
for the Electronic Load are included in the Operating Manual.
Related Documents
The following documents, shipped with each Electronic Load, are referenced in this manual:
Document Relevant Information
Agilent 6060B/6063B Operating Manual Agilent Part No.
5951-2826
Calibration procedures, local & specifications
remote operation.
Electronic Load Family Programming Reference Guide
Agilent Part No. 06060-90005
SCPI programming, status reporting
It is assumed that you are familiar with, or can obtain, the information in the above documents.
Firmware Revisions
Some information in this manual, and S.A. (signature analysis) information in particular, is associated with specific versions
of the Electronic Load firmware. Each Electronic Load returns the revision number of its primary interface firmware in
response to the "*IDN?" query. Both primary and secondary interface ROMs have a label that also specifies the firmware
revision. See "Signature Analysis" in Chapter 3.
Manual Revisions
Agilent instruments are identified by a two-part, ten-character serial number, such as 2847A-00101. The first five characters
(e.g. 2847A) are the serial prefix, which is the same for all identically made instruments. The last five digits (e.g. 00101) is
a unique serial number assigned to each instrument. If a significant design change is made, the prefix changes but the last
five numbers continue in sequence.
This manual was written for Electronic Loads with the same serial prefix and with serial numbers equal to or higher than the
ones shown on the title page. If the prefix number of your Electronic Load is higher than the one on the title page, then the
Electronic Load was made after publication of the manual and may have hardware and/or firmware differences not covered
in this manual. If there are such differences, they are documented in one or more "Manual Changes" sheets sent with the
manual.
