OmniSwitch 6850 Series Chassis and Hardware Components OmniSwitch 6850 Series Power Supplies
OmniSwitch 6850 Series Hardware Users Guide August 2007 page 2-77
PS-360W-AC Power Supply
The PS-360W-AC power supply (shown below) supplies full switch and Power over Ethernet (PoE) func-
tionality for 24-port OmniSwitch 6850 Series switches (e.g., OS6850-P24X). In addition, two 360W
power supplies support full switch and PoE functionality for 48-port OmniSwitch 6850 Series switches
(e.g., OS6850-P48X) while a single 360W power supply supplies switch but only partial support for PoE
on 48-port switches A single 360W allocates 240W for the POE functionality.
360W AC Power Supply
In addition, the 360W power supply can be installed as a primary or backup power supply. (See “Install-
ing Power Supplies” on page 2-80 for more information.)
