Console Port OmniSwitch 6850 Series Chassis and Hardware Components
page 2-72 OmniSwitch 6850 Series Hardware Users Guide August 2007
RJ-45 Console Port – Connector Pinout
Pin Number Signals as DTE Console Port
1NC
2NC
3RXD
4Ground
5Ground
6TXD
7NC
8NC
