OmniSwitch 6850 Series Chassis and Hardware Components Booting OmniSwitch 6850 Series Switches
OmniSwitch 6850 Series Hardware Users Guide August 2007 page 2-67
Booting Stacked Configurations
Once the switches have been connected to a virtual chassis, the next step is to manually power on the
stack. The OmniSwitch 6850 Series switch does not use an on/off switch. The power cord is the switch’s
only connect/disconnect device. The power connector socket is located on the switch’s rear panel. For
more information, refer to “Rear Panel” on page 2-56.
To boot the stack, plug the power cord (provided) into the power connector socket at the rear panel of each
switch in the stack. Next, plug all power cords, in rapid succession, into easily-accessible power sources,
such as grounded AC outlets or an Uninterruptible Power Supply (UPS).
Note. Be sure to power on all switches in the stack in rapid succession; otherwise, switches may be
assigned unintended stack management roles. Refer to Chapter 4, “Managing OmniSwitch 6850 Series
Stacks” for detailed information.
The stack immediately begins the boot process. Allow a few moments for all elements in the stack to boot
completely, then verify the status of all LEDs on the switch’s front panel. A successful boot for a stand-
alone switch displays the following LED states.
If any of the LED state differs from the states shown in the table above, refer to page 2-54 for more infor-
mation. Contact Alcatel-Lucent Customer Support if the LED state persists. For information on logging in
and configuring your OmniSwitch 6850 Series stack, refer to the OmniSwitch 6850 Series Getting Started
Guide and OmniSwitch 6800/6850/9000 Series Switch Management Guide.
LED States for a Stacked Configuration
OK Solid green for all switches.
PRI Solid green for the primary management module; solid amber for the
secondary management module; off for switches operating in idle roles.
Detailed information for primary, secondary, and idle roles is provided
in Chapter 4, “Managing OmniSwitch 6850 Series Stacks.”
PWR Solid green for all switches.
BPS Solid amber if BPS attached is failed and off when no operational
backup power supply (BPS) is attached; solid green if an operational
BPS is attached and operating normally.
XFP1 Off (applies to all OmniSwitch 6850 Series switches except for
OmniSwitch 6850-24X, OmniSwitch 6850-P24X, OmniSwitch 6850-
U24X, OmniSwitch 6850-48X, and OmniSwitch 6850-P48X). See
“Installing SFP and XFP Transceivers” on page 2-89 for more informa-
tion.
XFP2 Off (applies to all OmniSwitch 6850 Series switches except for the
OmniSwitch 6850-24X, OmniSwitch 6850-P24X, OmniSwitch 6850-
U24X, OmniSwitch 6850-48X, and OmniSwitch 6850-P48X). See
“Installing SFP and XFP Transceivers” on page 2-89 for more informa-
tion.
Slot Indicator 1–8 (non-blinking), depending on the slot number assignment for each
corresponding switch. See Chapter 4, “Managing OmniSwitch 6850
Series Stacks” for detailed information.
