OmniSwitch 6850 Series Chassis and Hardware Components OmniSwitch 6850-U24X
OmniSwitch 6850 Series Hardware Users Guide August 2007 page 2-19
OmniSwitch 6850-U24X
The OmniSwitch 6850-U24X is an edge/workgroup switch offering 24 1000Base-X SFP connectors, two
(2) 10 Gigabit XFP connectors, as well as four combo individually configurable to 10/100/1000Base-T.
The front panel of the OS6850-U24X chassis contains the following major components:
• System status and slot indicator LEDs
• (22) unshared 1000Base-X SFP connectors
• (2) shared combo 1000Base-X SFP connectors
• (2) Combo RJ-45 10/100/1000Base-T
• (2) 10 Gigabit XFP connectors
• Console port (RJ-45)
• USB port (USB 2.0)
Note. USB 2.0 is not supported in this release.
