OmniSwitch 6850-P24 OmniSwitch 6850 Series Chassis and Hardware Components
page 2-38 OmniSwitch 6850 Series Hardware Users Guide August 2007
OmniSwitch 6850-P24
The OmniSwitch 6850-P24 is a stackable edge/workgroup switch offering 20 unshared 10/100/1000 Base-
T Power over Ethernet (PoE), as well as four combo individually configurable to 10/100/1000 Base-T PoE
or 1000 Base-X high speed connections.
The front panel of the OS6850-P24 chassis contains the following major components:
• System status and slot indicator LEDs
• (20) unshared 10/100/1000Base-T PoE
• (4) shared combo 10/100/1000Base-T PoE
• (4) Combo SFP connectors for 1000Base-X connections
• Console port (RJ-45)
• USB port (USB 2.0)
Note. USB 2.0 is not supported in this release.
