Rockwell Automation Publication 1734-UM013C-EN-P - August 2010 109
Configure the Module for a SmartGuard Controller Chapter 7
Save and Download
Module Configuration
We recommend that after a module is configured you save your work.
If after downloading the program the MS and NS status indicators on the
POINT Guard I/O module are not both solid green, this may be due to loss of
ownership. The ownership is based on the following:
• POINT Guard I/O module number
• POINT Guard I/O safety network number
• SmartGuard slot number
• SmartGuard safety network number
• Path from SmartGuard controller to POINT Guard I/O module
• Configuration signature
If any of these change, the connection between the SmartGuard controller and
the POINT Guard I/O module is lost, and a yellow yield icon in the RSNetWorx
for DeviceNet tree appears. For more information, see Chapter
8.
