Rockwell Automation Publication 1734-UM013C-EN-P - August 2010 39
Chapter
3
Install the Module
Introduction
Follow these steps to install the modules.
1. Install the Mounting Base
.
2. Connect the Module to the Mounting Base
.
3. Connect the Removable Terminal Block
.
4. Wire Modules
.
Topic Page
Introduction 39
Environment and Enclosure 41
Preventing Electrostatic Discharge 41
Install the Mounting Base 42
Connect the Module to the Mounting Base 43
Connect the Removable Terminal Block 45
Remove a Mounting Base 46
Wire Modules 46
Set the Node Address of a POINT Guard I/O Module 48
Reset POINT Guard I/O Modules to Out-of-box Condition 50
Auto-addressing with a 1734-PDN Adapter and POINT Guard I/O
Modules
51
