C
Configuration Reference Information
What This Appendix
Contains
This appendix provides information about configuration settings.
Understand Parameter
Groups
The modules have these parameter groups: safety input, test output, safety
output. See the tables for the settings in each parameter group. All parameters are
set by using RSLogix 5000 software.
Parameter Name Value Description
x Input Delay Time
Off -> On
0…126 ms (in increments
of 6 ms)
Filter time for OFF to ON transition.
x Input Delay Time
On -> Off
0…126 ms (in increments
of 6 ms)
Filter time for ON to OFF transition.
x Input Point Mode Not Used External input device is not connected.
Safety Pulse Test Use with a contact output device and in combination with a test output. Using this
setting, short-circuits between input signal lines and the power supply (positive side)
and short-circuits between input signal lines can be detected.
Safety A solid-state output safety sensor is connected.
Standard A standard device, such as a reset switch, is connected.
x Safety Input Test Source Not Used The test output that is used with the input.
Test Output 0
Test Output 1
Test Output 2
Test Output 3
x Input Point Operation Type Single Channel Use as single channel.
Dual-channel Equivalent Use as dual-channel. Normal when both channels are ON or OFF.
Dual-channel
Complementary
Use as dual-channel. Normal when one channel is ON and the other channel is OFF.
x Safety Input Error Latch Time 0…65,530 ms
(in increments of 10 ms)
Safety input or test output errors are latched for this time. 1000 ms
