40 Rockwell Automation Publication 1734-UM013C-EN-P - August 2010
Chapter 3 Install the Module
Figure 14 - POINT Guard I/O Modules
Item Description
1 Slide-in writeable labels
2 Insertable I/O modules
3 Module locking mechanism
1
2
31867-M
3
