Rockwell Automation Publication 5069-UM004A-EN-P - April 2019 165

Configure a Standard Module Chapter 6

Connection Category

The Connection category lets you complete the following tasks:

• Set the RPI rate. For more information on the RPI, see

Requested

Packet Interval on page 47.

• Set the Connection over the EtherNet/IP network type of connection.

• Inhibit the module. For more information on how to inhibit the

module, see

page 73.

• Configure whether a connection failure while the controller is in Run

module causes a major or minor fault.

TIP The Module Fault area of the Connection category is useful during module

troubleshooting. For more information on the Module Fault area, see

page 225.
