Input Module Features Chapter 3
Compact 5000 I/O Safety Input Module
Table 14 lists tags that are used on Compact 5000 I/O safety input module.
For more information on fault reporting, see Appendix A,
Troubleshoot Your
Module on page 211.
IMPORTANT For more information on the valid values for each tag, see Appendix B,
Module Tag Definitions on page 231.
Table 14 - Compact 5000 I/O Safety Input Module - Fault and Data Status
Data Type Tag Name Triggering Event That Sets
Fault
ConnectionFaulted
(1)
The owner-controller loses its connection to the module.
Ptxx.Fault The point data quality is bad or the channel is set to Not Used.
Ptxx.ShortCircuit A short circuit condition exists on the point.
Testxx.Fault The point data quality is bad or the channel is set to Not Used.
Testxx.ShortCircuit A short circuit condition exists on the test point.
Testxx.FieldPowerOff A field power lost condition exists on the test point.
Status
RunMode The module is in Run Mode.
DiagnosticActive Indicates if any diagnostics are active or if the prognostics threshold is reached.
DiagnosticSequenceCount The count increments each time that a diagnostic condition is detected or removed.
Ptxx.Data The data currently at the point.
Ptxx.Uncertain The point data can be imperfect because an Over temperature or Critical Temperature condition exists.
Ptxx.Status The point state transitions from normal to faulted or faulted to normal.
Testxx.Readback A 24V DC power is present at the test output.
Testxx.Uncertain The test point data can be imperfect.
Testxx.Status The test point state transitions from normal to faulted or faulted to normal.
(1) This tag provides module-wide data an affects all channels simultaneously.
