Rockwell Automation Publication 5069-UM004A-EN-P - April 2019 265
Module Tag Definitions Appendix B
Output Tags
Table 85 describes the 5069-OB16F module output tags.
Table 85 - 5069-OB16F Module Output Tags
Name Size Definition Valid Values
TimeBase LINT Indicates the TimeBase for all schedule times in a
scheduled output consumed assembly or channel. The
TimeBase + The Schedule[n].TimeOffset determines the
time for the schedule. Base/Offset scheme that is used to
fit enough schedules into the assembly.
Any positive value.
Ptxx.Data BOOL Current input value. • 0 = Off
• 1 = On
Ptxx.ScheduleEn BOOL Specifies the use of normal output data or scheduled data. • 0 = Normal output data
• 1 = Scheduled data
Schedulex SINT Indicates which schedule to load from 32 available
schedules.
• 1…32 = Valid schedule
• 0, 129…255 = No schedule
Schedulex.ID SINT There are 32 schedules available (for Neo R1 products).
Indicates which schedule to load.
• 1…32 = Valid schedule
• 0 or 129…255 = No schedule
Schedulex.SequenceNumber SINT Indicates that the schedule information is valid and to
process this schedule.
All values.
Schedulex.OutputPointSelect SINT Selects the output point that this schedule applies to. 0xFF
means no output point selected.
0…15
Schedulex.Data BOOL Output data to be applied at time that is specified in
schedule.
0 or 1
Schedulex.TimeOffset DINT Offset from schedule base time. Used for scheduled output
consumed tags. Base/Offset scheme that is used to fit
enough schedules in the assembly.
All values.
