1 Publication 1762-RM001C-EN-P
Chapter
15
Sequencer Instructions
Sequencer instructions are used to control automatic assembly machines
or processes that have a consistent and repeatable operation. They are
typically time based or event driven.
Use the sequencer compare instruction to detect when a step is complete;
use the sequencer output instruction to set output conditions for each
step. Use the sequencer load instruction to load data into the sequencer
file.
The primary advantage of sequencer instructions is to conserve program
memory. These instructions monitor and control 16 (word) or 32 (long
word) discrete outputs at a time in a single rung.
You can use bit integer or double integer files with sequencer instructions.
Instruction Used To: Page
SQC - Sequencer Compare Compare 16-bit data with stored data 15-2
SQO - Sequencer Output Transfer 16-bit data to word addresses 15-5
SQL - Sequencer Load Load 16-bit data into a file 15-8
