15-8 Sequencer Instructions
Addressing Modes and File Types can be used as shown in the following
table:
SQL - Sequencer Load
Instruction Type: output
Table 15.4 SQO Instruction Valid Addressing Modes and File Types
For definitions of the terms used in this table see Using the Instruction Descriptions on page4-2.
Parameter
Data Files Function Files
CS - Comms IOS - I/O
Address
Mode
(1)
(1) See Important note about indirect addressing.
Address
Level
O I S B T, C, R N ST L MG, PD RTC HSC PTO, PWM STI EII BHI MMI DAT TPI Immediate Direct Indirect Element Bit Word Long Word
File
(2)
(2) File Direct and File Indirect addressing also applies.
•• • • •
• •••
Mask
(2)
•• ••• • • • •••
Destination
(2)
•• ••• • • •••
Control
(3)
(3) Control file only.
• •
Length
• •
Position
• •
IMPORTANT
You cannot use indirect addressing with: S, ST, MG, PD,
RTC, HSC, PTO, PWM, STI, EII, BHI, MMI, DAT, TPI, CS,
IOS, and DLS files.
EN
DN
SQL
Sequencer Load
File #N7:0
Source I:0.0
Control R6:0
Length 1<
Position 0<
SQL
Table 15.5 Execution Time for the SQL Instruction
Controller Data Size When Rung Is:
True False
MicroLogix 1200 word 21.7
µ
s7.0
µ
s
long word 24.3
µ
s7.1
µ
s
MicroLogix 1500 word 19.1
µ
s6.3
µ
s
long word 21.1
µ
s6.3
µ
s
