Allen-Bradley micrologix 1500 User Manual

Publication 1764-UM001B-EN-P - April 2002
3-14 Wiring Your Controller
1764-28BXB Wiring Diagram with Sinking Inputs
Input Terminals
Output Terminals (FET Outputs Are Sourcing Only)
IN 9
NOT
USED
IN 0 IN 2
DC
COM 1
IN 5
IN 7 IN 8
IN 10
NOT
USED
DC
COM 0
IN 1
IN 3 IN 4 IN 6
DC
COM 2
IN 11
IN 15
IN 14
IN 13
IN 12
-DC
+DC
-DC
+DC
“NOT USED” terminals are not intended for use as connection points.
+24v
OUT 10OUT 9
VAC/
VDC 3
OUT 7
OUT 5
OUT 3VDC 2
VAC/
VDC 1
VAC/
VDC 0
COM
OUT 11
VAC/
VDC 4
OUT 8
VDC
COM 2
OUT 6
OUT 4
OUT 2
OUT 1OUT 0
EARTH
GND
CR CR CR
CR CR
-DC
+DC
CR
