Allen-Bradley PowerFlex 40 Original Instructions

26 Rockwell Automation Publication 22-TD001I-EN-P - June 2013
PowerFlex 4 and 40 AC Drives
Flange Mount Drive
175
(6.89)
210
(8.27)
54.7
(2.15)
92.8
(3.65)
145
(5.71)
195
(7.68)
97.5
(3.84)
179
(7.05)
8
(0.31)
130
(5.12)
114
(4.49)
5.3
(0.21)
8
(0.31)
98
(3.86)
49
(1.93)
16
(0.63)
244
(9.61)
250
(9.84)
94.3
(3.71)
63.1
(2.48)
214
(8.43)
119.3
(4.70)
210
(8.27)
98
(3.86)
160
(6.30)
145
(5.71)
49
(1.93)
31
(1.22)
7.5
(0.30)
14
(0.55)
98.5
(3.88)
197
(7.76)
6.5
(0.26)
225
(8.86)
23.5
(0.93)
5.3
(0.21)
22B-CCB
Frame A — PowerFlex 4 only
Frame B— PowerFlex 4 and PowerFlex 40
