34 Rockwell Automation Publication 22-TD001I-EN-P - June 2013
PowerFlex 4 and 40 AC Drives
Specifications for Configured Drive Products
Drive Ratings — PowerFlex 40 Configured Drives
Catalog Number kW (HP)
Input Ratings Output Ratings
Voltage Amps Voltage Amps
23B-D1P4 0.4 (0.5) 480 1.8 460 1.4
23B-D2P3 0.75 (1.0) 480 3.2 460 2.3
23B-D4P0 1.5 (2.0) 480 5.7 460 4.0
23B-D6P0 2.2 (3.0) 480 7.5 460 6.0
23B-D010 4.0 (5.0) 480 13.0 460 10.5
23B-D012 5.5 (7.5) 480 14.2 460 12.0
23B-D017 7.5 (10.0) 480 18.4 460 17.0
23B-D024 11.0 (15.0) 480 26.0 460 24.0
Input/Output Ratings Output Frequency:
Efficiency:
0…400 Hz (Programmable)
97.5% (Typical)
Approvals
Fuses and Power Disconnecting
Means
140M Motor Circuit Protector:
194R Fused Disconnect:
Provides branch circuit protection, 65 kA short circuit withstand
Provides branch circuit protection, 200 kA short circuit withstand, Class J fuses
Protective Features Over Voltage:
Under Voltage:
480V AC Input – Trip occurs at 810V DC bus voltage (equivalent to 575V AC incoming line)
480V AC Input – Trip occurs at 390V DC bus voltage (equivalent to 275V AC incoming line)
Environment Ambient Operating Temperature:
Cooling Method:
NEMA 4/12, 4X (IP66), –10 to 40 degrees C (14 to 104 degrees F)
(1)
Fan, all drive ratings
(1) The design of the PowerFlex 40 Configured Drive supports indoor and outdoor applications that are not in direct sunlight.
Control Carrier Frequency: 2…4 kHz. Drive rating and heat calculations are based on 4 kHz.
U
L
®
L
I
S
T
E
D
9
6
6
X
I
N
D
C
O
N
T
E
Q
UL508C
U
L
®
L
I
S
T
E
D
9
6
6
X
I
N
D
C
O
N
T
E
Q
C
CSA C 22.2 No. 14 EN 61800-3
LV Directive 73/23/EEC
LV: EN 50178, EN 60204
EMC Directive 89/336/EEC
EMC: EN 61800-3
